Frame
Ransom Carbon HMF Mainframe with Alloy 6061 SwingarmIntegrated Suspension Technology, 6 Link kinematic, Adjustable head angleSyncros Cable Integration SystemBB92, UDH Interface, 12x148mm with 55mm Chainline, MX Ready
-
Fork
Marzocchi Z1, Rail 3 , LSC-LSR adjustable, 15x110mm, 44mm offset, Tapered steerer, 170mm travel
-
Rear Shock
Marzocchi Bomber Air, Scott Custom Tuned, Comp & Reb adjust, T205x65mm, 170mm travel
-
Rear Derailleur
SRAM Eagle 70 Transmission 12 Speed
-
Shifters
SRAM Eagle 70 Trigger
-
Crankset
SRAM Eagle 70 TransmissionDUB, 55mm CL, 34T
-
Chainguide
SCOTT custom
-
BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm
-
Chain
SRAM CN Eagle 70 Transmission
-
Cassette
SRAM Eagle XS 1270 V2 Transmission 10-52
-
Brakes
SRAM DB8 Stealth 4 Piston Disc
-
Rotors
SRAM Centerline Rotors F&R 200mm
-
Handlebar
Syncros Hixon 2.0 Alloy 6061 D.B.Size S & M 12mm Rise, Size L & XL 20mm Rise, back sweep 8°, 780mmSyncros AM lock-on grips
-
H'stem
Syncros AM 2.0Syncros Cable Integration System4° rise, 6061 Alloy, 31.8mm, 40mm
-
Seatpost
Syncros Duncan Dropper Post 1.5S, Travel Adjust, 31.6mmS size 140mm, M size 180mm, L & XL size 210mm
-
Seat
Syncros Tofino 2.0Crmo Rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula SCT-1905, 110x15mm, thru axle
-
Hub (Rear)
Formula SCT-1910148x12mm thru axle, sealed bearings
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Alexrims MD30 Disc, 32H black, 30mm, Tubeless Ready
-
Front Tire
Schwalbe Magic Mary 29x2.5", Trail, Radial, Ultra Soft, Tubeless ready120TPI Foldable Bead
-
Rear Tire
Schwalbe Albert 29x2.5", Gravity, Radial, Soft, Tubeless ready120TPI Foldable Bead
-
Accessories
Syncros IS Matchbox KitSyncros Multi-tool Matchbox 8
-
Approx weight in KG
16.64 (Tubless setup without matchbox IS )
-
Approx weight in LBS
36.68 (Tubless setup without matchbox IS )
-
Max. System Weight
130kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
