Frame
Ransom Carbon HMF Mainframe with Alloy 6061 Swingarm Integrated Suspension Technology 6 Link kinematic, Adjustable head angle Syncros Cable Integration System BB92, UDH Interface, 12x148mm with 55mm Chainline, MX Ready
-
Fork
RockShox Zeb Select+ Charger 3.1 HSC - LSC - LSR adjustable, 15x110mm Maxle stealth axle 42mm offset, Tapered Steerer, 170mm travel
-
Rear Shock
FOX FLOAT X NUDE EVOL Piggy Back Trunnion, SCOTT custom w. travel, geo adj. 3 modes: Climb-Ramp Control-Descend Custom large Air volume, Comp & Reb. Adj. Travel 170-130-Climb, T205X65mm, Bearing Hardware
-
Remote System
TracLoc Technology Rear Suspension & Dropper Remote 3 Rear Suspension modes
-
Rear Derailleur
SRAM S1000 Eagle AXS Transmission 12 Speed Wireless Electronic Shift System
-
Shifters
SRAM AXS Pod Controller
-
Crankset
SRAM Eagle 70 Transmission DUB, 55mm CL, 32T
-
Chainguide
SCOTT custom
-
BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm
-
Chain
SRAM CN Eagle 70 Transmission
-
Cassette
SRAM Eagle XS 1270 V2 Transmission 10-52
-
Brakes
SRAM Maven Bronze 4 Piston Disc
-
Rotor
SRAM HS2 Rotors F&R 200mm
-
Handlebar
Syncros Hixon 2.0 Alloy 6061 D.B. Size S & M 12mm Rise, Size L & XL 20mm Rise, back sweep 8°, 780mm Syncros AM lock-on grips
-
H'stem
Syncros AM 2.0 Syncros Cable Integration System 4° rise, 6061 Alloy, 31.8mm, 40mm
-
Seatpost
Syncros Duncan Dropper Post 1.5S, Travel Adjust, 31.6mm S size 140mm, M size 180mm, L & XL size 210mm
-
Seat
Syncros Tofino 2.0 Crmo Rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
-
Wheelset
Syncros Revelstoke HD1.5 IS F: 15x110mm, R: 12x148mm Boost 30mm Tubeless ready rim 28H Syncros Axle w/Removable Lever with Tool
-
Front Tire
Schwalbe Magic Mary 29x2.5", Trail, Radial, Ultra Soft, Tubeless ready 120TPI Foldable Bead
-
Rear Tire
Schwalbe Albert 29x2.5", Gravity, Radial, Soft, Tubeless ready 120TPI Foldable Bead
-
Extras
SRAM AXS Powerpack, RS Zeb Fender
-
Accessories
Syncros IS Matchbox kit Syncros IS tubeless Handlebar tool Syncros Multi-tool Matchbox 8
-
Approx weight in KG
16.9 (Tubless setup without matchbox IS )
-
Approx weight in LBS
37.26 (Tubless setup without matchbox IS )
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
