Frame
Carbon HMF Main Frame, Alloy SST-CST Integrated Suspension Technology Virtual 4 Link kinematic, Adjustable head angle Syncros Cable Integration System TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline
-
Travel
Front: 150mm, Rear: 155mm
-
Fork
Marzocchi Z2 Air Rail, Sweep Adj, 15x110mm QR axle, tapered steerer 44mm offset, Reb. Adj., Lockout, 150mm travel
-
Rear Shock
X-Fusion NUDE 5 RLX Trunnion SCOTT custom w. travel, geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 155-100-Lockout, T185X55mm
-
Remote System
SCOTT TracLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes
-
Drive Unit
TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph
-
Battery
TQ Internal 360Wh + TQ Range Extender 160Wh
-
Display
TQ HPR Bluetooth, ANT+, Dedicated Smartphone app
-
Charger
TQ 100-240V-4A
-
Rear Derailleur
SRAM Eagle 70 Transmission 12 Speed
-
Shifters
SRAM Eagle 70 Shifter
-
Crankset
Praxis Alloy
-
Chainguide
e*thirteen, e*spec Slider
-
Chainring
Praxis alloy spider, SRAM Eagle Transmission 34T chainring
-
Chain
SRAM CN Eagle 70 Transmission
-
Cassette
SRAM Eagle XS 1270 Transmission 10-52
-
Brakes
SRAM DB4 Stealth 4-Piston Disc
-
Rotor
SRAM HS2 Rotors F&R 200mm
-
Handlebar
Syncros Hixon 2.0 Alloy 6061 Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm Syncros Endurance lock-on grips
-
H'stem
Syncros AM 2.0 Syncros Cable Integration System 4° rise, 6061 Alloy, 31.8mm, 1 1/8"
-
Seatpost
Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm S size 140mm, M size 180mm, L size 180mm, XL size 210mm
-
Seat
Syncros Tofino 2.0 Regular
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System Stainless, +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula CL-148S, 12x148mm
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Syncros X-30S, 32H, 30mm, Sleeve Joint Tubeless ready
-
Front Tire
Maxxis Assegai, 2.5", 60TPI Foldable Tubeless Ready, EXO+ 3C Maxx Terra
-
Rear Tire
Maxxis Dissector, 2.5", 60TPI Foldable Tubeless Ready, EXO+ 3C Maxx Terra
-
Approx weight in KG
19.8 Tubless setup without RE (1.1kg)
-
Approx weight in LBS
43.65 Tubless setup without RE (1.1kg)
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
